Fiber 12 24 Cores MPO/MTP Fiber Optic Patch Panel Module Cassette
Overview:
Xuchuan TELECOM Model ODF-01 MPO/MTP Patch Panel is used to interconnect MTP/MPO backbones with LC or SC patching. It has been designed to accept LC duplex adaptors up to 96 fibers housed within a 1U space. YIPU high density MTP/MPO-LC Patch panel and cassettes address today's requirements for increasingly higher density levels, are fitted with 12 Fibers and have array adapters on the front side and MTP/MPO at the rear. This cassette is tailor-made for optimizing cable management, speed deployment, and improving flexibility and manageability for lower installation costs
Technical Index
|
Product name |
1U MPO&MTP-LC Rack mount patch panel |
Fiber Count |
Max.96 Fibers |
|
Enclosure Type |
Rack-Mountable |
Material |
CRS Cold rolled steel |
|
Installation |
Standard EIA 19" Rack |
Dimensions (HxWxD) |
482.6*455*44mm |
|
Compliant |
TIA/EIA-568-C.3 |
Advantage |
High-Density Patching System |
Features:
1. High-quality engineering plastics and Aluminum alloy or cold-rolled sheet material
2. MPO faceplate can be upgraded easily.
3. Available in 96 fibers configurations
4. All the front ports are with mark no. easy to identify.
5. High performance and reliability to provide narrow solutions for high-density application
6. Quick and easy install, flexible in configuration, and easy to management
|
Fiber Type |
SM Ferrule |
SM Low-Loss Ferrule |
MM Ferrule |
MM Low-Loss Ferrule |
|
Insertion Typical(dB) |
0.35 |
0.10 |
0.35 |
0.10 |
|
Insertion Maximum(dB) |
0.70 |
0.35 |
0.60 |
0.35 |
|
Return Loss(dB) |
PC≥50, UPC≥55, APC≥65 |
|||
|
Male/Female |
Male: With Pins Female: Without Pins |
|||
|
Repeatability(dB) |
≤0.2 (500 times) |
|||
|
Operating Temperature(ºC) |
-40~+85 |
|||
